Toshiba Tecra M10 - Removing the Harness Holder L

To Next Page

To Previous Page

4 Replacement Procedures 4.32 LCD harness

2. Turn over the cover assembly.

3. Lift up the hook of the harness holder L and slide the harness holder L to remove it

from the holes of the guides.

Harness holder L

Guide

Hook

Figure 4-62 Removing the harness holder L

4-102 [CONFIDENTIAL] TECRA M10 Maintenance Manual (960-685)
