Toshiba Tecra M10 - Replacing the 14.1-Inch WXGA Samsung Fluorescent Lamp

4.35 Fluorescent Lamp 4 Replacement Procedures
4.35.2 Replacing the 14.1-inch WXGA Samsung Fluorescent Lamp
CAUTION: When replacing the fluorescent lamp, wear finger covers or gloves to avoid
contaminating or damaging the LCD panel and backlight unit.
Removing the fluorescent lamp
To replace the 14.1-inch WXGA Samsung fluorescent lamp, follow the steps below and refer
to figures 4-76 to 4-79.
1. Remove the PCB cover.
CAUTION: Handle with care not to damage COF of S/D.
TECRA M10 Maintenance Manual (960-685) [CONFIDENTIAL] 4-119
PCB cover
Figure 4-76 Replacing 14.1-inch Samsung fluorescent lamp (WXGA) (1)
