Appendices Appendix B Board Layout

B.14 GPU board (FGGNM*) View: It is used by a GPU model.

(front)

(back)

Figure B-14 GPU board (FGGNM*) layout (front

/back

)

Table B-14 GPU

board

(FGGNM*) connector (

back

)

Number Name

CN5960 System board I/F connector

B-20 [CONFIDENTIAL]

TECRA M10 Maintenance Manual (960-685)
