Toshiba Tecra M10 - CN3010 MDC Interface Connector (12-Pin); CN4610 USB Interface Connector (4-Pin); CN4620 USB Interface Connector (4-Pin); Table

Appendices Appendix C Pin Assignments
C-32 [CONFIDENTIAL] TECRA M10 Maintenance Manual (960-685)
USB/MDC board (FG6US*/FGGUS*/FGAUS*)
C.32 CN3010 MDC interface connector (12-pin)
Table C-32 MDC interface connector (12-pin)
Pin No. Signal Name Pin No. Signal Name
1
GND
2
NC
3 AZSDO1-P3P 4 NC
5 GND 6 E3V
7 AZSYC1-P3P 8 GND
9 AZSDIM-P3P 10 GND
11 AZRST1-E3N 12 XAZBC1-P3P
1T GND 2T GND
3T GND 4T GND
5T GND 6T GND
C33 CN4610 USB interface connector (4-pin)
Table C-33 USB interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1
USB2PS-E5V
2
ZUSBP5-E3N
3 ZUSBP5-E3P 4 GND
1T GND 2T GND
3T GND
C34 CN4620 USB interface connector (4-pin)
Table C-34 USB interface connector (4-pin)
Pin No. Signal Name Pin No. Signal Name
1
USB1PS-E5V
2
ZUSBP0-E3N
3 ZUSBP0-E3P 4 GND
1T GND 2T GND
3T GND
