[29] My function [4/5] Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
Default setting
Vector control
Title
Communi
cation
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)
=
500V
-50Hz
=
575V
-60Hz
=
690V
-50Hz
Write
during
running
Speed
control
Tor qu e
control
V/f
Constant
Reference
0948 Input function command 62 Same as 1/1 0 0 0 Enabled ●/● ●/● ● *1
0949 Input function target 62 Same as 1/1 0 0 0 Enabled ●/● ●/● ● *1
0950 Input function command 63 Same as 1/1 0 0 0 Enabled ●/● ●/● ● *1
0951 Input function target 63 Same as 1/1 0 0 0 Enabled ●/● ●/● ● *1
0952
Output function assigned
object 6
Same as 1/1 0 0 0 Enabled ●/● ●/● ● *1
0953 Input function target 71 Same as 1/1 0 0 0 Enabled ●/● ●/● ● *1
0954 Input function command 72 Same as 1/1 0 0 0 Enabled ●/● ●/● ● *1
0955 Input function target 72 Same as 1/1 0 0 0 Enabled ●/● ●/● ● *1
0956 Input function command 73 Same as 1/1 0 0 0 Enabled ●/● ●/● ● *1
0957 Input function target 73 Same as 1/1 0 0 0 Enabled ●/● ●/● ● *1
0958
Output function assigned
object 7
Same as 1/1 0 0 0 Enabled ●/● ●/● ● *1
0959 Analog input function target 11
0:Disabled
1:VI/II
2:RR/S4
3:RX
4:Optional AI1+, Optional AI1-
5:Optional AI2
1/1 0 0 0 Enabled ●/● ●/● ● *1
0961
Analog function assigned
object 11
0:Disabled
1: Acceleration
2: Upper limit frequency ()
3:Acceleration multiplication factor
4:Deceleration multiplication factor
5: Manual torque boost ()
6:OC stall ()
7:Thermal protection ()
8:Speed loop P gain ()
9:Drooping gain ()
10:PID P gain ()
1/1 0 0 0 Disabled ●/● ●/● ● *1
*1: ⇒ For details, refer to Instruction Manual (E6581335) specified in Section 6.42.
