K-38
E6581528
11
[Contents of monitor displays] Sensorless vector/vector with sensor (●: valid, -: invalid)
Communi
cation No.
Function
Unit
(Commun
ication)
Monitor output
selection
Trip
retention
Meter
output
selection
Speed
control
Torque
control
V/f Reference
- Standard monitor - * 1
FE00 Trip frequency monitor 0.01Hz
when tripped when tripped
- ●/● ●/● ●
Contents of status monitor display
FE31 Pattern operation group selection -
at a pattern
operation
○ - ●/● - ●
FE32
Number of times to repeat current
pattern
1
at a pattern
operation
○ - ●/● - ●
FE33
Pattern operation - number of preset
speeds
1
at a pattern
operation
○ - ●/● - ●
FE34
Remaining time of current pattern
operation
1
at a pattern
operation
○ - ●/● - ●
FE01 Status (rotation direction) - Fixed ○ - ●/● ●/● ●
- Status monitor 1 -
* 1
- Status monitor 2 -
* 1
- Status monitor 3 -
* 1
- Status monitor 4 -
* 1
- Status monitor 5 -
* 1
- Status monitor 6 -
* 1
- Status monitor 7 -
* 1
- Status monitor 8 -
* 1
FE06 Input terminal information - Fixed ○ - ●/● ●/● ●
- Input terminal information (optional) - Fixed ○ - ●/● ●/● ●
- Input terminal information (optional) - Fixed ○ - ●/● ●/● ●
FE07 Output terminal information - Fixed ○ - ●/● ●/● ●
- Output terminal information (optional) - Fixed ○ - ●/● ●/● ●
FE08 CPU1 version 1 Fixed × - ●/● ●/● ●
FE73 CPU2 version - Fixed × - ●/● ●/● ●
FE10 Past trip 1 - Fixed × - ●/● ●/● ●
FE11 Past trip 2 - Fixed × - ●/● ●/● ●
FE12 Past trip 3 - Fixed × - ●/● ●/● ●
FE13 Past trip 4 - Fixed × - ●/● ●/● ●
FE79 Part replacement alarm information - Fixed × - ●/● ●/● ●
FE14 Cumulative operation time 1h Fixed × - ●/● ●/● ●
8.2.1
*1: Status in a trip may not be held depending on selected function. Refer to next page; ⇒ [Monitor FM/AM/pulse output function selection].
