Toshiba TSL3000E Series Interface Manual

– 55 –
INTERFACE MANUAL
STE 85457
Correspondence table
between [U07] set value (example) and [U08] program file name
Signal name in DIN command
Program file name
(EXTRNSEL.PAR)
4
3
2
1
"PROG1"
0
0
0
0
"PROG2"
0
0
0
1
"PROG3"
0
0
1
0
"PROG4"
0
0
1
1
"PROG5"
0
1
0
0
"PROG6"
0
1
0
1
"PROG7"
0
1
1
0
"PROG8"
0
1
1
1
"PROG9"
1
0
0
0
"PROG10"
1
0
0
1
"PROG11"
1
0
1
0
"PROG12"
1
0
1
1
"PROG13"
1
1
0
0
"PROG14"
1
1
0
1
"PROG15"
1
1
1
0
"PROG16"
1
1
1
1
When bits underlined = 1 2, two (2) external digital input signals 1 and 2 are used,
and the number of program files selected is four (4) from "PROG1" ~ "PROG4".
To register the program file name to the program number, register on the
EXTRNSEL.PAR file.
