69
Installation and Maintenance
Service Manual
The data above are subject to change without notice.
NO.
Description
Part Code
QtyTM24HFDI
Product Code CN210N0100_L81561
1 Air outlet frame assy 01375224 1
2 Cover of air outlet 01265335 1
3 Water Tray Assy 01285334 1
4 Evaporator Assy 01024269 1
5 Lower Cover Plate Sub-Assy 01265339 1
6 Left Side Plate Assy 01315334 1
7 Plate of the Evaporator Sub-Assy 01495317 1
8 Plate of the Exit Tube Sub-Assy 01495316 1
9 Front volute casing 26905205 3
10 Rear volute casing 26905206 3
11 Bottom Cover Plate 01265337 1
12 Transformer 43110233 1
13 Terminal Board 420001000002 1
14 Main Board 30226338 1
15 Capacitor 3301074704 1
16 Electric Box Sub-Assy 01395100 1
17 Electric Box assy 01395985 1
18 Electric Box Cover 01424253 1
19 Cover Plate of the Fan 01265338 1
20 Temperature Sensor 39000206 1
21 Ambient Temperature Sensor 390001982G 1
22 Fan Motor 15010100007401 1
23 Bar Clasp 70818405 1
24 Supporter 01805288 1
25 Joint Slack 73018731 1
26 Supporter 01895225 1
27 Rotary Axis Sub-Assy 73018022 1
28 Centrifugal fan 10425200 3
29 Fan Mounting Plate Assy 01325316 1
30 Right Side Plate Assy 01305263 1
31 Display Board 30296317 1
32 Water Pump Assy 15405241 1
33 Water Level Switch 45010201 1
34 Water Pump 43130324 1
35 Remote Controller 305100492 1
To Next Page
