NO.
Description
Part Code
Qty
TM09HTDI
TM12HTDI
TM18HTDI TM24HTDI
Product Code
CN610N0060_L81561
CN610N0070_L81561
CN610N0050_L81561 CN610N0080_L81561
1 Fixed Mount 26909426R 26909426R 26909426R 1
2 Louver Clamp 26112127 26112127 26112127 2
3 Guide Louver 10619403 10619403 10619403 1
4 Rotating Shaft 26909430 26909430 26909430 4
5 Front Connecting Plate 01349414P 01349414P 01349414P 1
6 Base Frame 26909448 26909448 26909448 1
7 Air Lead Plate sub-assy 02229418 02229418 02229418 1
8 Supporter(Motor) 01805288 01805288 01805288 1
9 Mid-clapboard sub-assy 01249427 01249427 01249427 1
10 Front volute casing 26905205 26905205 26905205 4
11 Rear side plate assy 1319440 1319440 1319440 1
12 Centrifugal fan 10425200 10425200 10425200 4
13 Support 1 01809417 01809417 01809417 1
14 Right Side Plate Sub-Assy 01319429 01319429 01319429 1
15 Right Cover Plate 26909444 26909444 26909444 1
16 Installation Supporting Frame(Right) 01809402 01809402 01809402 1
17 Connection Board(Right) 02229406 02229406 02229406 1
18 Joint Slack 73018731 73018731 73018731 2
19 Rear Connecting Plate 01349422 01349422 01349422 1
20 Fan Motor 1570940901 150101000074 15709409 1
21 Bar Clasp 70818405 70818405 70818405 1
22 Bar Clasp Sub-assy 70815201 70815201 70815201 1
23 Rear volute casing 26905206 26905206 26905206 4
24 Rubber ring 76513101 76513101 76513101 1
25 Filter 2 07216221 07216221 07216221 1
26 Ambient Temperature Sensor 390001978G 390001978G 390001978G 1
27 Evaporator Assy 01029482 01029469 1029474 1
28 Press Plate of Water Lead ume 26909442 26909442 26909442 1
29 Connection Board(Evaporator) 01344115 01344115 02229428 1
30 Water Tray Assy 01289404 01289404 01289404 1
31 Front Grill sub-assy 01579403 01579403 01579403 1
32 Top Cover Board Sub-assy 01269409 01269409 01269409 1
33 Support 2 01809418 01809418 01809418 1
34 Left Side Plate Sub-Assy 0131942801 0131942801 0131942801 1
35 Rotating Shaft 26909412 26909412 26909412 1
36 Rotating Shaft 26909413 26909413 26909413 1
37 Step Motor 1521240206 1521240206 1521240206 1
38 Electric Box Assy 02404651 02404653 02404654 1
39 Left Cover Plate 26909443 26909443 26909443 1
40 Installation Supporting Frame(Left) 01809401 01809401 01809401 1
41 Display Board 30296317 30296317 30296317 1
42 Remote Controller 305100491 305100491 305100491 1
43 Display Board 30294220 30294220 30294220 1
44 Terminal Board 420001000002 420001000002 420001000002 1
45 Capacitor CBB61 3301074716 3301074710 3301074704 1
46 Electric Box Cover 01429420 01429420 01429420 1
47 Transformer 43110257 43110257 43110257 1
48 Main Board 30226350 30226350 30226350 1
49 Electric Box 01429419 01429419 01429419 1
50 Room Sensor 3900019822 3900019822 3900019822 1
