48
Installation and Maintenance
Service Manual
NO.
Malfunction
Name
Display Method of Indoor Unit
A/C status Possible Causes
Dual-8
Code
Display
Indicator Display (during
blinking, ON 0.5s and OFF
0.5s)
Operation
Indicator
Cool
Indicator
Heating
Indicator
43
Malfunction of
phase current
detection
circuit for
compressor
U1
During cooling and drying
operation, compressor will stop
while indoor fan will operate;
During heating operation, the
complete unit will stop
Replace outdoor control panel AP1
44
Malfunction of
voltage
dropping for
DC bus-bar
U3
During cooling and drying
operation, compressor will stop
while indoor fan will operate;
During heating operation, the
complete unit will stop
Supply voltage is unstable
45
Malfunction
of complete
units current
detection
U5
During cooling and drying
operation, the compressor will
stop while indoor fan will
operate;
During heating operating,
the complete unit will stop
operation.
Theres circuit malfunction on
outdoor units control panel AP1,
please replace the outdoor units
control panel AP1.
46
The four-way
valve is
abnormal
U7
If this malfunction occurs
during
heating operation, the complete
unit will stop operation.
1.Supply voltage is lower than
AC175V;
2.Wiring terminal 4V is loosened or
broken;
3.4V is damaged, please replace
4V.
47
Zero-
crossing
malfunction of
outdoor unit
U9
During cooling operation,
compressor will stop while
indoor fan will operate; during
heating,the complete unit will
stop operation.
Replace outdoor control panel AP1
48
49
Defrosting
U8
50
JF
off for
0.5s and
then
blinks
for 10s
Not the error code. It’s the status code for the operation
51 E9
Not the error code. It’s the status code for the operation
The complete unit stops
1.Power supply is abnormal;
2.Detection circuit of indoor
control mainboard is abnormal.
Malfunction
of detecting
plate(WIFI )
Cold air
prevention
protection)
52 oE
Cool: compressor and
outdoor fan stops operation,
while indoor fan operates;
Heat: compressor, outdoor
fan and indoor fan stop
1. Outdoor ambient temperature
exceeds the operation range of
unit (eg: less than-20℃ or more
than 60oC for cooling; more than
30oC for heating);
2. Failure startup of compressor?
3. Are wires of compressor not
connected tightly?
4. Is compressor damaged?
5. Is main board damaged?
Undefined
outdoor unit
error
Loads operate normally,
while the unit can’t be
normally controlled by APP.
1.Main board of indoor unit is
damaged;
2.Detection board is damaged;
3.The connection between
indoor unit and detection board
is not good;
To Next Page
