Tosot TW09HQ3D6DO User Manual

65
Installation and Maintenance
Service Manual
NO.
Description
Part Code
Qty
TW09HQ3D6DI TW12HQ3D6DI
Product Code CB460N05700_L81560 CB460N01400_L81560
1 Decorative Strip / / /
2 Front Panel 27230010219 27230010219 1
3 Display Board 300001000042 300001000042 1
4 Filter Sub-Assy 1112208906 11122089 2
5 Decorative Board (Left) 20192662 20192662 1
6 Front Case 2002248401 2002248401 1
7 Guide Louver 1051276501 1051276501 1
8 Axile Bush 10542036 10542036 2
9 Air Louver 1 10512733 10512733 2
10 Helicoid Tongue 26112512 26112512 1
11 Left Axile Bush 10512037 10512037 1
12 Rear Case assy 00000100001 00000100001 1
13 Rubber Plug (Water Tray) 76712012 76712012 1
14 O-Gasket sub-assy of Bearing 76512051 76512051 1
15 Ring of Bearing 26152025 26152025 1
16 Evaporator Support 24212177 24212177 1
17 Evaporator Assy 011001000457 0100200001401 1
18 Cross Flow Fan 10352060 10352060 1
19 Fan Motor 15012136 15012136 1
20 Motor Press Plate 26112511 26112511 1
21 Wall Mounting Frame 01362026 01362026 1
22 Connecting pipe clamp 2611218801 2611218801 1
23 Crank 73012005 73012005 1
24 Stepping Motor 1521240212 1521240212 1
25 Drainage Hose 05230014 05230014 1
26 Electric Box Assy 100002063934 100002001263 1
27 Lower Shield of Electric Box 01592139 01592139 1
28 Electric Box 2011221105 2011221105 1
29 Jumper 4202021922 4202021925 1
30 Main Board 300002000366 300002000366 1
31 Air Louver 10512736 10512736 1
32 Stepping Motor 1521210704 1521210704 1
33 Air Louver 2 10512735 10512735 1
34 Swing Lever 10512731 10512731 1
35 Decorative Board (Right) 20192662 20192662 1
36 Screw Cover 2425201726 2425201726 3
37 Electric Box Cover2 20112210 2011221001 1
38 Shield Cover of Electric Box Cover 01592176 01592176 1
39 Electric Box Cover 2011220901 2011220901 1
40 Terminal Board 42011233 42011233 1
41 Power Cord / / /
42 Connecting Cable / / /
43 Connecting Cable / / /
44 Remote Controller 305001000082_TOSOT 305001000082_TOSOT 1
45 Detecting plate(WIFI) 300018000046 300018000046 1
Above data is subject to change without notice.
