Tosot TW09HQ3D6DO User Manual

67
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
QtyTW18HQ3D6DI TW24HQ3D6DI
Product Code CB460N01300_L81560 CB460N01600_L81560
1
Decorative Strip / / /
2
Front Panel Assy 00000200057 00000200057 1
3
Display Board 300001000042 300001000042 1
4
Filter Sub-Assy 11012007 11012007 2
5
Decorative Board (Left) 20192655 20192655 1
6
Front Case 2002248603 2002248603 1
7
Guide Louver 1051232001 1051232001 1
8
Axile Bush 10542036 10542036 2
9
Air Louver 1 10512741 10512741 2
10
Helicoid Tongue 26112513 26112513 1
11
Left Axile Bush 10512037 10512037 1
12
Rear Case assy 22202736 22202736 1
13
Rubber Plug (Water Tray) 76712012 76712012 1
14
O-Gasket of Cross Fan Bearing 76512203 76512203 1
15
Ring of Bearing 26152025 26152025 1
16
Evaporator Support 24212178 24212178 1
17
Evaporator Assy 01100100007301 011001000095 1
18
Cross Flow Fan 10352057 10352057 1
19
Fan Motor 15012136 15012136 1
20
Motor Press Plate 26112515 26112515 1
21 Wall Mounting Frame 01252229 01252229 1
22 Connecting pipe clamp 26112514 26112514 1
23 Crank 73012005 73012005 1
24
Stepping Motor 1521240212 1521240212 1
25
Drainage Hose 0523001405 0523001405 1
26
Electric Box Assy 100002001271 100002001272 1
27
Lower Shield of Electric Box 01592139 01592139 1
28
Electric Box 2011221105 2011221104 1
29
Jumper 4202021926 4202021929 1
30
Main Board 300002000366 300002000366 1
31
Air Louver 10512744 10512744 1
32
Stepping Motor 1521240212 1521240212 1
33
Air Louver 2 10512742 10512742 1
34
Swing Lever 10512743 10512743 1
35
Decorative Board (Right) 20192655 20192655 1
36
Screw Cover 2425245301 2425245301 3
37
Electric Box Cover2 2011221001 2011221001 1
38
Shield Cover of Electric Box 01592139 01592139 1
39
Electric Box Cover 2011220901 2011220901 1
40
Terminal Board 42011233 42011233 1
41
Power Cord / / /
42
Connecting Cable / / /
43
Connecting Cable / / /
44
Remote Controller 305001000082_TOSOT 305001000082_TOSOT 1
45
Cold Plasma Generator / / /
46
Detecting plate(WiFi) 30070077 30070077 1
