Method Of Usage Method Of Usage
Prepare the handle controller frame assembly in step 3.(figure 7)
Insert the handle controller frame assembly in to the cylindrical fixed pipe, be carefully
( Figure 7) ( Figure 8)
Prepare two screws which tighten on two sides (figure 9)
( Figure 9) ( Figure 10)
9.Controller installation and usage
Insert the handle controller in to the frame (figure 1), the frame can turn left and rig ht
freely. (Figure 2) and the handle controller can swing freely in horizontal direction.
( Figure 1)
( Figure 2)
( Figure 3)
ENLARGE
FIGURE
Put the cylindrical fixed pipe in to the hole on the right armrest, take care that the
sthere hole on the fixed pipe should be one to one corresponded with the hole on
the arm rest of the flange plate. (figure 5)
Screw three screws to tighten it ( figure 6)
( Figure 5) ( Figure 6)
Note: the gap should be
face down and vertical to the earth
£1£
£2£
10.The disassemble and using of pillow pad and back cushion
You can weaken the kneading strength of the neck and shoulder by pillow pad, you
can use it according to your requirement (Advise you use it). Back cushion connect
with back by zipper (1), pillow pad connect with the back cushion by fastener (2)
Zipper
Fastener
To Next Page
