This box contains:
Instruction Manual
1. Thermometer and screw nut N
2. Handle of cover
3. Cover
4. Grill Plate
5. Grease pan
6. Base of appliance
7. Stand tube
8. Centre base
9. Side table
10. U-shaped tube
11. Straight tube
12. Rack
13. Plastic rack holder
14. Feet pads
15. C butterfly screw + D washer
16. Handle of base
17. Opening for appliance socket
18. Removable temperature controller
19. Temperature control dial
20. Appliance socket
Specifications:
Screws list:
(A)
Screw
(x 4)
(B)
Screw
(x 4)
(C)
Butterfly
Screw
(x 8)
(D)
Washer
(x 8)
(E)
Screw
(x 4)
(F)
Screw
(x 2)
This screw
is used to
tighten the
handle on
the lid
1
2
3
4
5
6
7
8
9
10
11
12 13
14
15
16
17
18
19
20
