C90569
–AUTOMATIC TRANSMISSION / TRANS TRANSMISSION REVOLUTION SENSOR
40–23
2098Author: Date:
2002 CAMRY REPAIR MANUAL (RM881U)
8. INSTALL TRANSMISSION REVOLUTION SENSOR(NT
SENSOR)
(a) Coat an O–ring with ATF.
(b) Install the transmission revolution sensor with the bolt.
Torque: 11.3 N⋅m (115 kgf⋅cm, 8 ft⋅lbf)
HINT:
Make sure of the manufacturer’s name.
(c) Connect the transmission revolution sensor connector.
9. INSTALL AIR CLEANER HOSE NO.1
10. INSTALL AIR CLEANER ASSY
Torque: 5.0 N⋅m (51 kgf⋅cm, 44 in.⋅lbf)
11. INSTALL ENGINE COVER SUB–ASSY NO.1
To Next Page
