183
2004 ECHO S/D from Feb. ’04 Prod. (OM52573U)
NOTICE
Your ground clearance is re-
duced when the compact spare
tire is installed so avoid driving
over obstacles and drive slowly
on rough, unpaved roads and
speed bumps. Also, do not at-
tempt to go through an auto-
matic car wash as the vehicle
may get caught, resulting in
damage.
SM41004a
1. Get the required tools and
spare tire.
Vehicles with compact spare tire
1. Jack handle
2. Wheel nut wrench
3. Jack
4. Spare tire
To prepa r e yo u r self for an em erge n c y,
you should familiarize yourself with
the use of the jack, each of the tools
and their storage locations.
SU41028a
Turn the jack joint by hand.
To remove: Turn the joint in direction
1 until the jack is free.
To store: Turn the joint in direction 2
until the jack is firmly secured to pre-
vent it flying forward during a collision
or sudden braking.
04 01.06
—Required tools and spare
tire
To Next Page
