’05 MATRIX_U (L/O 0409)
32
2005 MATRIX from Sep. ’04 Prod. (OM12892U)
1. To open the fuel filler door, pull the
lever up.
When refueling, turn off the engine.
CAUTION
! Do not smoke, cause sparks or al-
low open flames when refueling.
The fumes are flammable.
! When opening the cap, do not re-
move the cap quickly. In hot weath-
er, fuel under pressure could cause
injury by spraying out of the filler
neck if the cap is suddenly re-
moved.
2. To remove the fuel tank cap, turn
the cap counterclockwise by 90 de-
grees (to the pressure point 1), and
then turn it an additional 30 degrees
(to point 2). Pause slightly before
removing it.
It is not unusual to hear a slight swoosh
when the cap is opened.
3. The removed cap can be stored on
the back side of the fuel filler door.
Position the cap so that the hooks point
to the left and right, and set it in the
receptacle on the back side of the door.
To Next Page
