Toyota 2010 4RUNNER NAVIGATION SYSTEM User Manual

532
4-3. Do-it-yourself maintenance
After a system failure, see “Fuse layout and amperage rat-
ings” (→P. 5 35 ) fo r d eta i ls a bo u t wh i c h f u se t o c h ec k .
Remove the fuse.
Only type A fuse can be
removed using the pull-out
tool.
Check if the fuse is blown.
Type A
Normal fuse
Blown fuse
Replace the blown fuse with a
new fuse of an appropriate
amperage rating. The amper-
age rating can be found on the
fuse box lid.
Type B
Normal fuse
Blown fuse
Replace the blown fuse with a
new fuse of an appropriate
amperage rating. The amper-
age rating can be found on the
fuse box lid.
STEP 3
STEP 4
CTH43AS029
STEP 5
CTH43AS030
CTH43AS031
