4
OVERVIEW
Indicator symbols
Instrument cluster
Service indicator and reminder
Tachometer
Speedometer
Fuel gauge
Outside temperature
Odometer/Trip meter reset/Instrument panel light control
Engine coolant temperature
Automatic Transmission shift range display (if equipped)
Odometer and two trip meters
Charging system warning
1
Brake system warning
1
AIR BAG ON and AIR BAG OFF indicator
Driver seat belt reminder
(alarm will sound if speed is over 12 mph)
Front passenger seat belt reminder
(alarm will sound if speed is over 12 mph)
For details, refer to “Indicators and warning lights,” Section 2-2, 2011
Owner’s Manual.
1
If indicator does not turn off within a few seconds of starting engine, there may
be a malfunction. Have vehicle inspected by your Toyota dealer.
414843M2.qxd:414843M2 11/18/10 9:44 AM Page 4
