453
6-1. Specifications
6
Vehicle specifications
Brakes
*
1
: Minimum pedal clearance when depressed with a force of 66 lbf (294 N, 30
kgf) while the engine is running
*
2
: 2.4 L 4-cylinder (2AZ-FE) engine with 18-inch tires or AWD models
*
3
: Parking brake lever travel when pulled up with a force of 44 lbf (200 N, 20
kgf)
Pedal clearance*
1
1.8 L 4-cylinder (2ZR-FE) engine
3.4 in. (87 mm)
2.4 L 4-cylinder (2AZ-FE) engine
• AWD models: 3.4 in. (87 mm)
• 2WD models with P215/45R18 tires:
3.4 in. (87 mm)
• 2WD models with tires other than the
above: 3.3 in. (85 mm)
Pedal free play 0.04 ⎯ 0.24 in. (1 ⎯ 6 mm)
Brake pad wear limit 0.04 in. (1.0 mm)
Parking brake lining wear limit*
2
0.04 in. (1.0 mm)
Parking brake lever travel*
3
6 ⎯ 9 clicks
Fluid type SAE J1703 or FMVSS No.116 DOT 3
To Next Page
