Power Source
HEAD Relay
3–5 : Closed with the light control SW at Head position or the dimmer SW at Flash position
: Closed with the engine running and the parking brake lever is released (Parking brake SW off)
I10 Ignition SW
1–3 : Closed with the ignition SW at ACC or ON position
1–2 : Closed with the ignition SW at ON or ST position
5–6 : Closed with the ignition SW at ON or ST position
5–4 : Closed with the ignition SW at ST position
: Parts Location
Code See Page Code See Page Code See Page
G2 32 J6 35
I10 35 J7 35
:
Relay Blocks
Code See Page Relay Blocks (Relay Block Location)
1 22 Engine Room R/B (Engine Compartment Left)
3 28 RH R/B (Right Side of the Instrument Panel Reinforcement)
:
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
IA
25
Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
IB
25 Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
IF
25
IH
25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
IM 24
()
1A
22
Engine Wire and Engine Room J/B (Engine Com
p
artment Left)
1B
22 Engine Wire and Engine Room J/B (Engine Compartment Left)
1C
22
Engine Room Main Wire and Engine Room J/B (Engine Com
p
artment Left)
1D
22 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
:
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IA4 40 Engine Room Main Wire and Instrument Panel Wire (Left Side of the Instrument Panel Reinforcement)
:
Ground Points
Code See Page Ground Points Location
IE 40 Behind the Combination Meter
IG 40 Right Kick Panel
Service Hints
