Toyota COROLLA2004 - Page 84

2004 COROLLA (EWD533U)
84
Taillight
C12 Combination SW
10–13 : Continuity with the light control SW at Tail or Head position
TAIL Relay
5–3 : Closed with the light control SW at Tail or Head position
: Parts Location
Code See Page Code See Page Code See Page
C12 34 J1 33 L1 36
D2 34 J6 35 L2 36
F3 32 J8 A 36 R9 37
F4 32 J9 B 36 R11 37
:
Relay Blocks
Code See Page Relay Blocks (Relay Block Location)
3 28 RH R/B (Right Side of the Instrument Panel Reinforcement)
:
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
IB
25
Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
IC
25 Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
ID 25 Floor Wire and Instrument Panel J/B (Lower Finish Panel)
IH 25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
IL 24
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
1A 22 Engine Wire and Engine Room J/B (Engine Compartment Left)
1C 22 Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
4B 30 Instrument Panel Wire and Center J/B (Behind the Combination Meter)
:
Ground Points
Code See Page Ground Points Location
EA 38 Front Right Fender
ED 38 Front Left Suspension Tower
IE 40 Behind the Combination Meter
BH 44 Under the Left Quarter Pillar
BI 44 Lower Back Panel
:
Splice Points
Code See Page Wire Harness with Splice Points Code See Page Wire Harness with Splice Points
I4 42 Instrument Panel Wire
Service Hints
