2004 COROLLA (EWD533U)
92
Interior Light
D4, D5, D6, D7 Door Courtesy SW Front LH, RH, Rear LH, RH
1–Ground : Closed with the door open
L4 Luggage Compartment Light SW
1–Ground : Closed with the luggage compartment door open
: Parts Location
Code See Page Code See Page Code See Page
C9 34 I11 A 35 J10 36
D4 36 I12 36 L3 36
D5 36 I13 36 L4 36
D6 36 J6 35 M2 37
D7 36 J7 35 R7 35
:
Relay Blocks
Code See Page Relay Blocks (Relay Block Location)
1 22 Engine Room R/B (Engine Compartment Left)
:
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
IC 25 Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
ID 25 Floor Wire and Instrument Panel J/B (Lower Finish Panel)
IE 25 Roof Wire and Instrument Panel J/B (Lower Finish Panel)
IF
IG
25
IH
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
IK
24
()
IL
24
4B
30
Instrument Panel Wire and Center J/B (Behind the Combination Meter)
4C
30 Instrument Panel Wire and Center J/B (Behind the Combination Meter)
:
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
IK1 42 Roof Wire and Instrument Panel Wire (Left Side of the Instrument Panel Reinforcement)
:
Ground Points
Code See Page Ground Points Location
IE 40 Behind the Combination Meter
IG 40 Right Kick Panel
:
Splice Points
Code See Page Wire Harness with Splice Points Code See Page Wire Harness with Splice Points
B1 44 Roof Wire
Service Hints
