2004 COROLLA (EWD533U)
97
A2 Back–Up Light SW (A/T)
2–3 : Closed with the shift lever at R position
B1 Back–Up Light SW (M/T)
2–1 : Closed with the shift lever at R position
: Parts Location
Code See Page Code See Page Code See Page
A2 32 J8 A 36 R10 37
B1 32 J9 B 36 R12 37
J4 35 J10 36
:
Junction Block and Wire Harness Connector
Code See Page Junction Block and Wire Harness (Connector Location)
ID 25 Floor Wire and Instrument Panel J/B (Lower Finish Panel)
IG 25
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
IK 24
Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
3A
28
Instrument Panel Wire and RH J/B (Right Side of the Instrument Panel Reinforcement)
3B
28 Instrument Panel Wire and RH J/B (Right Side of the Instrument Panel Reinforcement)
:
Connector Joining Wire Harness and Wire Harness
Code See Page Joining Wire Harness and Wire Harness (Connector Location)
II2 42 Engine Wire and Instrument Panel Wire (Blower Unit RH)
:
Ground Points
Code See Page Ground Points Location
BH 44 Under the Left Quarter Pillar
BI 44 Lower Back Panel
Service Hints
