TP-Link Archer TX3000E - Initial Installation Steps

05
Chapter 2 Connect to a Computer
1. Turn off your computer, unplug the power cable then remove the case panel.
2. Connect the provided USB cable to the adapter.
3. Locate an available PCIE X1 slot and carefully insert the adapter.
Tip: If the bracket is not suitable for your computer, detach it from the adapter’s board and replace it with
the low-profile bracket.
