Choose the menu Switching→LAG→Static LAG to load the following page.
Figure 6-10 Manually Config
The following entries are displayed on this screen:

LAG Config
Group Number
: Select a Group Number for the LAG.
Description
: Displays the description of the LAG.

Member Port
UN IT:
Click unit number to configure the physical ports of this unit
member.
Member Por
t:
Select the port as the LAG member. Clearing all the ports of
the LAG will delete this LAG.
Tips:
1. The LAG can be deleted by clearing its all member ports.
2. A port can only be added to a LAG. If a port is the member of a LAG, the port number will be
displayed in gray and cannot be selected.
6.2.3 LACP Config
LACP (Link Aggregation Control Protocol) is defined in IEEE802.3ad and enables the dynamic link
aggregation and disaggregation by exchanging LACP packets with its partner. The switch can
dynamically group similarly configured ports into a single logical link, which will highly extend the
bandwidth and flexibly balance the load.
With the LACP feature enabled, the port will notify its partner of the system priority, system MAC,
port priority, port number and operation key (operation key is determined by the physical
properties of the port, upper layer protocol and admin key). The device with higher priority will lead
the aggregation and disaggregation. System priority and system MAC decide the priority of the
device. The smaller the system priority, the higher the priority of the device is. With the same
