TP-Link Tapo L930-5 - Appearance; Control Button Functionality; LED Status Indicators

3
Appearance
The Tapo Smart Light Strip includes a power adapter, a control button, a controller, and the Light Strip.
Power Adapter
Control Button
Light Strip
Controller
Control Button
Reset Descriptionription
Soft Reset
(Only reset Wi-Fi info)
Press and hold the button for 5s but no
more than 10s and release. The light
strip will blink orange and green.
Factory Reset
(Reset to factory settings)
Press and hold the button for at least
10s until the light strip turns solid white
then blinks orange and green.
LED Light Status
LED Status Descriptionription
Blinks orange and green Ready for setup
Blinks green and white Connecting to Wi-Fi
Blinks among several colors,
then remains solid white
Connected to Wi-Fi and TP-Link
server
