15
Chapter 4
Configure the Router in Wireless Router Mode
• Channel Width - The current wireless channel width in use.
• MAC Address - The physical address of the router.
• Internet - This field displays the current settings of the Internet, and you can configure
them on the Network > Internet page.
• MAC Address - The physical address of the WAN port.
• IP Address - The current WAN (Internet) IP Address. This field will be blank
or 0.0.0.0 if the IP Address is assigned dynamically and there is no internet
connection.
• Subnet Mask - The subnet mask associated with the WAN IP Address.
• Default Gateway - The Gateway currently used is shown here. When you use
Dynamic IP as the internet connection type, click Renew or Release here to
obtain new IP parameters dynamically from the ISP or release them.
• DNS Server - The IP addresses of DNS (Domain Name System) server.
4. 2. Operation Mode
1. Visit http://tplinkwifi.net, and log in with the password you set for the router.
2. Go to Operation Mode.
3. Select the working mode as needed and click Save.
