16
TP Children’s Wooden Playhouse
13
MW2453 530mm x3
MW2456 1172mm x1
90°
Slide position option
Board MW2456 or MW2455
will need to be cut
during Stage 20.
ASSEMBLY TIP
3 x 40mm
x16
FA4540
TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 16TP415 Childrens Wooden Playhouse IN0415-A 14.05.20 LITHUANIA.indd 16 14/05/2020 14:5814/05/2020 14:58
