TP Children’s Wooden Playhouse
15
MW2459 795mm x2
MW2460 1135mm x2
x2
16
MW2459 MW2459
MW2460
MW2460
Drill 3mm
ø
Locating hole
IMPORTANT
ASSEMBLY TIP
5mm
Approx
x4
22.5mm
25mm
MW2457 160mm x2
3 x 40mm
x8
FA4540
