TP Challenger Trampoline with SurroundSafe
4
5
1
3
Stage
5
8ft FC8000 x42
10ft FC8000 x60
12ft FC8000 x72
14ft FC8000 x80
x1
2
Logo style
may vary
Assembly Tip
1) Place mat inside
trampoline frame.
2) Orientate logo
to face trampoline
frame where there
are no legs.
Logo style
may vary
