TP Challenger TP541 - Stage 11: Lacing the Safety Surround; Surround to Mat Lacing

19
18
TP Challenger Trampoline with SurroundSafe
A
B
C
B
10
PM2080 x1
8ft, 10ft, 12ft & 14ft
1 2 3
Stage
10
Stage
11
C
8ft 7.3m FB6043 x1
10ft 9.1m FB6045 x1
12ft 11m FB6047 x1
14ft 13.56m FB6046 x1
B
Thread four holes/loops
then pull tight.
Repeat until back to start
A
Assembly Tip
Select adjacent hole in
surround when lacing the
surround to mat D-ring tab.
D-ring
Tab
