Specifications
Mains Voltage:
100-120 vac - 50/60Hz - T3.15AL/250V
230 vac - 50/60Hz - T1.6AL/250V
Power Consumption:
Typical = 30W
Maximum = 240W
SMPS:
ermal protection
Over-current protection
Power Amplier:
Protection:
Clip limiting
ermal
Over-current / Short-circuit
DC output
Minimum Load:
4 Ω
example--
1 - 4 Ω cabinet / 2 - 8 Ω cabinets
Power Output (1% THD):
130W - 8 Ω - Internal 8 ohm speaker
200W - 4 Ω - With external 8 ohm cab
Noise:
-62.5 dBu
Pre Amplier:
Nominal Input Sensitivity:
All controls @12:00 = -6.44dBu (369mV)
Input Impedance:
>10 meg Ω
EQ:
3 - band rotary type with proprietary TE lters
Low center = 80 Hz
Mid center = 400 Hz
High center = 4.2 KHz
DI XLR Balanced Output:
PIN 1 = GND, PIN 2 = sig+, PIN 3 = sig-
Post EQ
1 KΩ output impedance
w/GND li switch
noise 
oor = -104.3dBu
noise oor w/sig (nom.) = -88dBu
Weight:
(1x8) 18.7 lb (8.5 Kg)
(1x10) 18.5 lb (8.4 Kg)
(1x12) 31.4 lb (14.5 Kg)
(1x12 Ext.) 28.1 lb (12.85 Kg)
Dimensions (H x W x D):
1x8:
11” (27.94cm) x 10.25” (26.035cm) x 13.37” (33.95cm)
1x10
12.75” (32.38cm) x 12” (30.48cm) x 14” (35.56cm)
1x12
15” (38.1cm) x 14” (35.56cm) x 16.5” (41.91cm)
Warranty registration and information for U.S. customers available online at
www.traceelliot.com/warranty
or use the QR tag below
