Chapter 6 UCMs supported by Tracer Summit systems
86 BMTX-SVN01C-EN
Device addressing
Each UCM must have a unique address on each link. Voyagers can have
an address from 50 through 81. The Voyager address is set using DIP
switches on the TCI-3 board and must match the address set in Site Con-
figuration for Tracer Summit. Refer to the TCI-3 literature for more
details about setting the address. For Voyager address DIP switch set-
tings, refer to Table 24.
Table 24. Voyager rooftop unit UCM address settings
UCM
address
TCI Board DIP switch settings
SW1-2 SW1-3 SW1-4 SW1-5 SW1-6
50 OFF OFF OFF OFF OFF
51
OFF OFF OFF OFF on
52
OFF OFF OFF on OFF
53
OFF OFF OFF on on
54
OFF OFF on OFF OFF
55
OFF OFF on OFF on
56
OFF OFF on on OFF
57
OFF OFF on on on
58
OFF on OFF OFF OFF
59
OFF on OFF OFF on
60
OFF on OFF on OFF
61
OFF on OFF on on
62
OFF on on OFF OFF
63
OFF on on OFF on
64
OFFonononOFF
65OFFonononon
66 on OFF OFF OFF OFF
67 on OFF OFF OFF on
68 on OFF OFF on OFF
68 on OFF OFF on on
70 on OFF on OFF OFF
71 on OFF on OFF on
72 on OFF on on OFF
73onOFFononon
74 on on OFF OFF OFF
75 on on OFF OFF on
76 on on OFF on OFF
