Tree FB Series - Materials and Ambient Conditions

EN-8 FBx Series Bench Scale
Figure 3-1. FBx Series Bench Scale.
Base
A
B
C
D
E
Total
Height
Total
Wdth
Total
Length
Dimension from
Indicator bottom
to the ground
Dimension
from Platform
surface to the
ground
FBx-m1824
33inch
18inch
29inch
26inch
6inch
FBx-m2424
33inch
24inch
29inch
26inch
6inch
3.2 Technical Data
Materials
• Indicator Housing: Stainless steel
• FBS scale structure: stainless steel; FB scale structure: cast steel
• Keypad/display overlay: Polyester
• Feet: Rubber
Ambient conditions
The technical data is valid under the following ambient conditions:
Ambient temperature: -10°C to 40°C / 14°F to 104°F
Relative humidity: Maximum relative humidity 80% for temperatures up
to 31°C decreasing linearly to 50% relative humidity
at 40°C.
Height above sea level: up to 4000m
