7
Step 9
Attach skids to the bottom of the legs using
four M6 x 50 mm hex bolts, eight washers and
four M6 lock nuts. With the help of others, turn
the feeder to the upright position.
Step 10
Attach spring latch to front of hopper using one
M6 x 15 mm bolt, washer (outside hopper) and
one rubber washer, washer and M6 lock nut
(inside hopper).
