Trevi Outline - Page 15

Ref. Description
1 Front cover plate
2 Wall plate for Trevi Therm & Traditional
2a Cover plate sealing rings
3 Cover plate fixing screws 50 mm
3a Cover plate fixing screws 60 mm
4d Outline temperature handle cover slip
4e Trevi Therm Temperature handle cap
5 Traditional volume control handle cap
5d Outline volume handle cover slip
5e Trevi Therm volume handle cap
6a Traditional volume handle
6d Outline volume handle
6e Trevi Therm volume handle
7c Traditional temperature handle index
7d Outline temperature handle
7e Trevi Therm Temperature handle
8 Self tapping handle screw
8b Long volume handle screw
9 Standard Shroud
9a Traditional Volume control handle shroud
Ref. Description
10 Volume control handle carrier
10a Traditional volume control handle insert
11 Gear box cover
12 Gear box sealing washer
13 Gear box cover fixing screws
14 Gear/clutch wheels complete
15 Gear/ wheel drive shaft
16 Gear/clutch wheels
17 Gear box back plate
18 1/2” cartridge
19 Thermostatic control cartridge
20 Temperature handle extension
21 Temperature adjustment carrier complete
22 Blanking plug
23 Outline wall plate
24 Traditional temperature handle
25 Flushing adapter outlet
26 Mounting template/plaster guide
27 Mounting template/plaster guide screws
SPARE PARTS 14
