Tri-Tronics Label-Eye LER - Page 2

070-0150 Rev 3
DIMENSIONS
SPECIFICATIONS
Made in U.S.A.
A
LABEL OPACITY
PLACE GAP OR
WEB ON DOT
BLU
BLK
BRN
WHT
10 to
30 VDC
LOAD
150MA MAX
NEG
PNP
LOAD
POS
NPN
T
R
TM
S
L
U
OUTPUT
AUTOSET
R
L
N
www.ttco.com
O
R
M
A
N
T
N
E
C
3
4
12
1
2
3
4
RED
BROWN* (1)
WHITE
BLACK* (4)
GREEN
BLACK
BLUE* (3)
GRAY* (5)
BLUE
WHITE* (2)
NPN
AUTOSET INPUT
REMOTE
LOAD
(SOURCE)
NEG
PNP
(SINK)
30 VDC
10 TO
LOAD
POS
BROWN* (1)
RED
WHITE* (2)
WHITE
BLACK* (4)
BLACK
GREEN
BLUE* (3)
LOAD
LOAD
(SOURCE)
NEG
PNP
(SINK)
NPN
POS
30 VDC
10 TO
5 (ONLY ON REMOTE
M12 CONNECTOR
PINOUT
M8 CONNECTOR
PINOUT
* SENSORS WITH CONNECTORS
6" [152.40] PIGTAIL
CONNECTOR
(M12 MODELS)
* SENSORS WITH CONNECTORS
AUTOSET MODELS)
6' (1.83 METERS)
CABLE
3.641"
(92.47 mm)
0.709"
(18.00 mm)
2.116"
(53.76 mm)
0.117"
(2.98 mm )
0.926"
(23.53 mm )
0.709"
(18.00 mm)
1.071"
(27.21 mm )
2X Ø0.167"
(Ø4.25 mm)
0.984"
(25.00 mm)
0.630"
(16.00 mm )
2.520"
(64.00 mm)
0.472"
(12.00 mm)
2X 6-32 X 1/4" DEEP
MOUNTING HOLES
P.O. BOX 25135, TAMPA, FL 33622-5135
813-886-4000 / 800-237-0946
ttco.com / info@ttco.com
Nano Cable (M8) Selection Guide
P/N
Length Thread Coupling
GEC-6 6 ft. (1.8m Straight Female
GEC-15 15 ft. (4.6m) Straight Female
RGEC-6 6 ft. (1.8m) 90° Female
RGEC-15 15 ft. (4.6m) 90° Female
RoHS Compliant
Product subject to change without notice.
SUPPLY VOLTAGE
• 10 to 30 VDC
• Polarity Protected
• Intended for use in class two circuits
CURRENT REQUIREMENTS
• 45 milliamps (exclusive of load)
OUTPUT TRANSISTORS
• (1) NPN and (1) PNP output transistors
• Sensor outputs can sink or source up to 150 milliamps (current
limit)
• All outputs are continuously short circuit protected
REMOTE AUTOSET INPUT
• opto isolated momentary sinking input (10 milliamps)
Note: Remote models only
RESPONSE TIME
• Light state response = 100 microseconds
• Dark state response = 100 microseconds
LED LIGHT SOURCE
• High intensity red LED
• Pulse modulated
PUSH BUTTON CONTROL
• Automatic set-up routines based on web opacity
• One push button set-up
• Simultaneously pushing both buttons inverts the output
HYSTERESIS
• Minimal hysteresis promotes the detection between the
backing material and the label depending on the settings
LIGHT IMMUNITY
• Responds to sensor’s pulsed modulated light source …
immune to most ambient light
INDICATORS
• Green LED flashes when AUTOSET routine is activated and
stays illuminated when AUTOSET is completed
• Red LED illuminates when sensors output transistors are
“ON”.
Note: The status of the output transistors can be inverted by
pushing both buttons simultaneously.
AMBIENT TEMPERATURE
• –40°C to 70°C (-40°F to 158°F)
RUGGED CONSTRUCTION
• Chemical resistance to harsh cleaners such as detergents,
alcohols, and ketones
• Waterproof, ratings: NEMA 2
• Conforms to heavy industry grade CE and UL requirements
Model Numbers:
Label•Eye
Description
LER Red LED, 4 conductor 6 ft. cable
LERC Red LED, 4-pin Nano connector
LERR Red LED, 5 Conductor, 6 ft. Cable
LERRC-M12 Red LED, 5-Pin M12 Pigtail Connector
LERC-M12 Red LED, 4-Pin M12 Pigtail Connector
