Triax TMS 5XX SE AQ-EU Series User Manual

EN
5
Technical Specifications:
Range
Single
6 or 8
Single
12 or 16
Single
24 or 32
Cascade
6 or 8
Cascade
12 or 16
Cascade
24 or 32
outputs
outputs
outputs
outputs
outputs
outputs
Functionality
1 x SAT position Multiswitch, single (stand-alone) or cascade versions
LNB type
1 x Universal QUATTRO LNB (AQ version uses QUAD LNB)
LNB Inputs (SAT polarities)
4
4
4
4
4
4
TER Input
1
1
1
1
1
1
Trunk outputs (cascade)
NA
NA
NA
5
5
5
Connectors
Type
F-connectors, IEC 60169-24, (female)
Impedance
Ω
75
Frequency Range SAT
MHz
950-2400
Frequency Range TER
MHz
40-862 (active) / 5-862 (passive)
TAP Loss SAT
dB
-2…+3 ±2
-2…+3 ±2
-6…0 ±2
-4…0 ±2
-4…0 ±2
-4…0 ±2
TAP Loss TER (active)
dB
-2 ±2
-2 ±2
-2 ±2
-3 ±3
-3 ±3
-3 ±3
TAP Loss TER (passive)
dB
-24 ±3
-24 ±3
-24 ±3
-33 ±3
-33 ±3
-33 ±3
THROUGH Loss SAT
dB
NA
NA
NA
-2…-4 ±2
-3…-4 ±2
-2…-6 ±2
THROUGH Loss TER
dB
NA
NA
NA
-3 ±2
-2 ±2(12)
-3 ±2(24)
-2…-6 ±2
Isolation T/S (typ.)
dB
30
30
30
30
30
30
Isolation H/V (typ.)
dB
30
30
30
30
30
30
In/Out Return Loss SAT
dB
>10
>10
>10
>10
>10
>10
In/Out Return Loss TER
dB
>10
>10
>10
>10
>10
>10
Max. Output Level SAT
(IMD3 @ 35 dB)
dBµV
101
101
101
101
101
101
Max. Output Level TER
(IMD3 @ 60 dB) - active
dBµV
90
88
88
84
84
84
LNB Supply Voltage
VDC
18
18
18
18
18
18
LNB Supply Current (Max.)
mA
500
500
500
900
900
900
Current cons. (from STB)
mA
27
29…38
29…38
35
27…35
27…35
Current Cons. (from PSU)
mA
120
10…250
10…250
7 /
100
10 / 100…350
10 / 100…350
Mains Voltage
VAC/Hz
90…264 /
50-60
90…264 /
50-60
90…264 /
50-60
NA
NA
NA
DC connector
Type
None, -R types: RCA/cinch/phono female
Cascade types: 5,5mm/2.1mm DC plug *)
Switch Commands
VDC/kHz
13/18 VDC, 0/22kHz, DiSEqC 1.0
Power Supply
Type
Fixed/
Included
R-Type: none
Fixed/
Included
R-Type: none
Fixed/
Included
R-Type: none
*) For external PSU w/EU-Mains plug:
318150, TMS 1520-55, 2,0A, or
318152, TMS 1533-55, 3,3A
R-types can use: 318154, TMS 1520-RCA
Please visit www.triax.com for details on individual weight, dimensions and part numbers
