ASSEMBLY INSTRUCTIONS
© 2020 TRINITY - 800.985.5506
2
Turn Cooler upside down. Align LEG (D) with
holes on bottom of TUB (A). Attach LEG (D)
with SMALL SCREWS (E). Make sure to
tighten securely.
Align HANDLES (F) on each side of TUB (A).
Attach HANDLE (F) with LARGE SCREW (G).
Make sure to tighten securely. HANDLES (F)
can be attached either angled up or down
based on your preference.
STEP 1
STEP 2
F (2) G (12)
A (1)
D (4) E (8)
Phillips
F
A
G
D
E
Phillips
