Trinity TXK-0802 - Install Drain Plug; Install Lid and Initial Cleaning

© 2020 TRINITY - 800.985.5506
4
Set LID (B) on top of TUB (A).
Clean the inside of Cooler thoroughly
before use.
Unscrew DRAIN PLUG (J) assembly. Insert
DRAIN PLUG (J) through the opening in TUB
(A) from the inside. Make sure the rubber
seal is on the inside of TUB (A).
From the outside, slide the Washer on first,
then the second Washer with Chain, and
then screw on the Nut. Be sure not to
overtighten. Once DRAIN PLUG (J) is in place,
screw on the Cap.
STEP 5
STEP 6
ASSEMBLY INSTRUCTIONS
J (1)
B (1)
B
Inside the tub
Outside the tub
J
