Trinity TXKPGR-0501 - Service Parts List

TXKPGR-0501 (45”) TXKPGR-0502 (36”)
Part Number Description Part Number Description
1) ZSV-01-001-0830 Lift Bolt 1) ZSV-01-001-0830 Lift Bolt
2) ZSV-01-008-0807 Lift Nut 2) ZSV-01-008-0807 Lift Nut
3) PBK-09-015-0001 Gas Lift 3) PBK-09-015-0001 Gas Lift
4) ZBK-01-004-0510 Handle Screw 4) ZBK-01-004-0510 Handle Screw
5) PGR-05-003-1600 45” Handle – Gray 5) PGR-05-003-1200 36” Handle – Gray
6) ZBK-01-004-0630 Lid Screw 6) ZBK-01-004-0630 Lid Screw
7) XSV-01-019-0612 Lid Washer 7) XSV-01-019-0612 Lid Washer
8) XSV-01-020-0608 Lid Split Washer 8) XSV-01-020-0608 Lid Split Washer
9) XSV-01-018-0606 Lid Nut 9) XSV-01-018-0606 Lid Nut
10) PGR-17-001-4524 45” Lid – Gray 10) PGR-17-001-3616 36” Lid - Gray
TRINITY Customer Service provides the following replacement parts:
SERVICE PARTS LIST – TXKPGR-0501 / 0502
4
7
6
9
3
8
© 2019 TRINITY - 800.985.5506
1
1
2
5
10
