Header
Installation
7
STEP 3. Header installation
Tools Fasteners Reference
Screwdriver no.2
(Down side, upside )
Flat neoprene washer #10”(12X), Screw #10
-32 x 3/4”(12X)
Screwdriver no.2
(right and left side fan’s cover)
BAG/BIN NO: Flat neoprene washer
#14”(12X), BAG/BIN NO : Screw 1/4"-20x
3/4”(12X)
Place the header on the machine as shown
To Next Page
