Seat assembly
Parts
25
ITEM PART NUMBER DESCRIPTION
1 SD-450-0003 PIVOT ASSEMBLY
2 SD-450-0008 ACTUATOR MOTOR AKM 24D
3 SD-450-0022 DRIVE ASSY AC10
4 SD-250-0068 ACTUATOR PLATE
5 SD-400-0010 SKIRT, RUBBER BASE
6 SD-900-0015 CAP PIVOT PISTON
7 SD-450-0013 CONTROL BOX "B"
8 SD-350-0015 FIBER GLASS SEAT
9
SD-500-0040
HEAD CUSHION
10
SD-500-0039
BACK REST CUSHION
11
SD-700-0070
3" SPEAKER ASSEMBLY
12
SD-250-0336
GRILL
13
SD-150-0019
NETWORK CABLE
14 IMT- 0151 SOUND WIRING HARNESS
