15
6: Fox 2 and Hound 3 Control Locations
(See Figures 1 and 2)
TRACER TONE
VISUAL CONT.
TALK
OFF / POLARITY
AUDIBLE CONT.
WARBLE
PULSE
UNLOCK
BATTERY TEST
AC / RING
REV NORM
CORDLESS
INTERFACE
G
RJ-45 Jack
H
Battery Test / Cadence LED
I
Warble / Pulse Button
A
Cordless Interface
B
Continuity / Talk LED
C
Unlock Button
D
Function Switch
E
Polarity LEDs
D
A
C
B
E
F
F
RJ-45 to RJ-11 Adaptor
G
H
I
J
Alligator Clips
J
Figure 1
FOX Control Locations
