Installation
2. Connect the RJ-45 ports on the transmitter and receiver units
with Cat5e/Cat6 cable.
Notes:
• For the B203-101-IND and B203-104-IND models, the distance
between the transmitter and receiver units must not exceed 150 ft.
(45 m).
• For the B203-101-IND-ER and B203-104-IND-ER models, the
distance between the transmitter and receiver units must not
exceed 330 ft. (100 m).
3. Connect a USB 2.0 device to each available port on the
receiver unit.
4. For the B203-101-IND-ER and B203-104-IND-ER models,
connect the included external power supply to the receiver
unit and then to an AC outlet using the correct plug adapter.
(Optional) External power (9V to 36V) can also be added by
using the RS-232 Phoenix connector.
Note: Only one power source should be connected to the receiver
unit(s), never both.
5. For the B203-101-IND and B203-104-IND models only:
(Optional) if connecting power-hungry device(s), use either
the included external power supply or RS-232 Phoenix
connector to add external power.
Note: Only one power source should be connected to the receiver
unit(s), never both.
