Tripp Lite B320-4X1-HH-K1 User Manual

15
Installation
Routing Functions
Command:
• swN M
Variations:
• N: stands for Connect Output N, default 1
• M: switch to input M
Response:
• CMD: swN M
Response Example:
• sw1 a
• CMD: sw1 A
Output 1, Select Input A
• sw2 b
• CMD: sw2 B
Output 2, Select Input B
Power Functions
Command: pwd
Response: PW
Stands for Power On/Off
• pwd
• CMD: PWD
Special Commands
Command: ste
Response: OutputN M[STATE]
Variations:
• N: Output N
• M: Input M
• [STATE]:
o [Signal] signal on from input
o [Idle] no signal from input
State of the output channel
• STE
• CMD: STATE
• Output1 A[Idle]
• Output2 A[Idle]
20-05-301-93-3C5E.indd 1520-05-301-93-3C5E.indd 15 6/2/2020 11:36:45 AM6/2/2020 11:36:45 AM
