3. Attaching the Display to the Stand
To prevent the display from tipping, anti-fall wire rope should be installed.
1100-1350 mm
(43.3-53.1 in.)
P-C
P-C
40 mm
(1.6”)
ø 3.5 mm
(ø 1/8”)
40 mm
(1.6”)
ø 7 mm
(ø 9/32”)
1100-1350 mm
(43.3-53.1 in.)
400-650 mm
(15.7-25.6 in.)
400-650 mm
(15.7-25.6 in.)
P-E
P-F
P-E
P-B
P-A
P-A
P-D
P-B
P-A
P-A
P-D
3.2
MAINTENANCE: Check at regular intervals (at least every 3 months) to make sure the display is secure and safe to use.
