6
Installation
3
B D FC E G
H
Attach the panel to
the enclosure using
four screws
H
. Before
completely tightening the
screws, adjust the two
claws to hold the tablet
and to ensure the screen
is aligned and visible
through the front panel.
Choose the corresponding panel according to the tablet.
Panel
B
: For 9.7" iPad 5/6, iPad Air 1/2 & iPad Pro (Gen 1)
Panel
C
: For 10.2" iPad 7 /8/9 & 10.5" iPad Air 3, iPad Pro (Gen 2)
Panel
D
: For 11" iPad Pro (Gen 3/4/5) & 10.9" iPad Air 4
Panel
E
: For 10.4" Samsung Galaxy Tab A7
Panel
F
: For 10.1" Samsung Galaxy Tab A
Panel
G
: For 10.4" Samsung Galaxy Tab S6
To Next Page
