Tritech T5 - Page 45

45
REV 8/2022
T5 FLUID MANIFOLD
PARTS LIST
NOTE: Items in bold are included in 600-455 packing kit
OPTIONAL MANIFOLD FILTERS
600-141-05 MANIFOLD FILTER, 50 MESH
600-141-10 MANIFOLD FILTER, 100 MESH
PACKING REMOVAL TOOL
602-667 PACKING REMOVAL TOOL
602-668 PACKING REMOVAL TIPS (2)
ITEM # PART # DESCRIPTION QTY
1 600-211 FILTER HOUSING 1
2 600-255 FILTER SPRING 1
3 600-141-02 MANIFOLD FILTER, 20 MESH 1
4 600-240 FILTER CORE 1
5 600-353 O-RING 1
6 600-033-75 UPPER RETAINER 1
7 600-035 UPPER GUIDE 1
8 600-017 UPPER PACKING 1
9 600-0083-75 PUMP HOUSING 1
10 600-037 NIPPLE, 1/4" NPT X 1/4" NPS, SST 1
11 600-024 LOWER PACKING 1
12 600-099-75 PISTON ROD 1
13 600-047 UPPER BALL 1
14 101-001 O-RING 1
15 600-142-75 PISTON VALVE 1
16 600-090-75 PISTON ROD COMPLETE (Includes 12-15) 1
17 600-022 LOWER BALL 1
18 600-021 INTAKE VALVE SEAT 1
19 600-234 GASKET 1
20 600-013 INTAKE VALVE HOUSING 1
21 600-279 O-RING 1
22 600-353 O-RING 1
23 600-367 O-RING 1
24 600-087 GUIDE, BALL / PISTON 1
25 599-199 HEX BOLT 2
26 600-166 O-RING 1
27 600-157 PRIME / SPRAY VALVE (Includes 26 & 35) 1
28 600-437 HANDLE & CAM KIT (Includes 29) 1
29 600-214 PIN 1
30 600-208 FITTING, HOSE BARBED 1
31 600-242 PLUG (Stand & Lo Cart Only) 2
32 600-320 PAIL HOOK (Hi Cart Only) 1
33 600-541 SCREW (Hi Cart Only) 2
34 599-222 LOCK WASHER 2
35 600-174 GASKET 1
36 600-335 PUMP COMPLETE 1
600-455
PACKING KIT Includes the following items:
(7,8,11,13,14,17,21,22,23)
